Product Description
2BA Zinc Plated Steel Pan Slotted Head Machine Screws
2BA zinc plated steel machine screws with a pan head and slotted drive. Suitable for repairs and assembly work using matching British Association threaded nuts or tapped holes.
Specifications
| Specification | Details |
|---|---|
| Thread Size | 2BA |
| Thread Series | British Association |
| Threads Per Inch | 31.4 TPI |
| Length | 1/2 inch (12.7mm) |
| Material | Steel |
| Finish | Zinc plated |
| Head Type | Pan head |
| Drive Type | Slotted |
| Listed Head Diameter | 0.36 inch |
| Listed Head Height | 0.10 inch |
Available Size
- 2BA x 1/2 inch - 31.4 TPI
Key Features
- British Association thread
- Steel construction with zinc plated finish
- Pan head with a flat bearing surface
- Slotted drive for a flat blade screwdriver
- Suitable for matching 2BA assemblies
BS 93 is the reference standard for British Association screw threads. Please contact us before ordering to confirm compliance certification availability.
Installation
Length is measured from beneath the head to the tip. Use a screwdriver blade that fits the slot correctly and ensure the mating thread is 2BA. Start the screw by hand to avoid cross-threading.
Useful Links
Specifications are intended as a guide. Confirm the required thread, length and head dimensions before ordering.
