Product Description
M5 Brass Square Section Spring Washers
M5 spring washers manufactured from brass with a square-section profile. Suitable for compatible M5 fastening assemblies where a brass spring washer is specified.
The split spring form compresses as the joint is tightened. Brass provides a matching appearance alongside brass nuts, bolts and other fittings.
Technical Specifications
| Nominal fixing size | M5 |
|---|---|
| Material | Brass |
| Washer style | Split spring washer |
| Section type | Square |
| Listed bore dimension | 5mm |
| Outside diameter | 8.5mm |
| Section thickness | 1.6mm |
Key Features
- Brass construction.
- Square-section spring profile.
- Compact 8.5mm outside diameter.
- Suitable for matching M5 fastening applications.
Applications
Suitable for fittings, equipment maintenance, restoration and general assembly where brass spring washers are required. Select the washer to suit the mating fastener, bearing surface and joint requirements.
Ordering
Choose the required pack quantity from the available options.
Dimensions are listed guide measurements. Section thickness refers to the washer material and is not the overall height of the uncompressed spring washer. Please confirm critical dimensions before ordering.
