M2.5 Metric A2 Stainless Steel Countersunk Pozi Head Set Screws DIN 965Z
These M2.5 countersunk Pozi machine screws are manufactured from A2 stainless steel and feature a metric coarse thread. The countersunk head sits flush with the surface when fitted into a correctly prepared countersunk hole, providing a neat finish.
The PZ1 Pozi drive allows installation with a matching screwdriver or bit. A2 stainless steel provides corrosion resistance for many general engineering and assembly applications.
Technical Specifications
| Thread Size | M2.5 |
|---|---|
| Nominal Thread Diameter | 2.5 mm |
| Thread Pitch | 0.45 mm |
| Thread Type | Metric coarse |
| Material | A2 stainless steel |
| Head Style | Flat countersunk |
| Drive Type | Pozi |
| Driver Size | PZ1 |
| Head Diameter | 4.4–4.7 mm |
| Maximum Head Height | 1.5 mm |
| Standard | DIN 965Z |
Available Lengths
| Thread Size | Overall Length |
|---|---|
| M2.5 x 0.45 | 4 mm |
| M2.5 x 0.45 | 6 mm |
| M2.5 x 0.45 | 10 mm |
Countersunk screw length is measured over the full length of the screw, including the head.
Selecting Your Screws
Select the required length and pack quantity from the available options. Use with a matching M2.5 x 0.45 nut or tapped hole and a correctly fitting PZ1 screwdriver or bit.
Ensure the countersink suits the screw head and keep the driver fully engaged during tightening to avoid damaging the recess.
