Product Description
M10 metric coarse A2 stainless steel hexagon head bolts to DIN 931, with a part threaded shank.
These part threaded hexagon bolts are manufactured from A2 stainless steel, also known as 304 stainless steel, offering good corrosion resistance for engineering, machinery, maintenance, automotive and outdoor fastening applications. The plain shank section can be useful where alignment, location or additional shear support is required.
- M10 metric coarse thread hexagon bolts
- A2 stainless steel, also known as 304 stainless steel
- DIN 931 part threaded hexagon bolt pattern
- Part threaded with plain shank
- M10 x 1.5mm standard metric coarse thread
- 17mm A/F hexagon head size
- 6.4mm head height
- Available in lengths from 35mm to 250mm
| A | B | C | D | E | F | G |
| 10mm | 100mm | 26mm | 17mm | 6.4mm | 1.5 | 74mm |
| 10mm | 40mm | 26mm | 17mm | 6.4mm | 1.5 | 14mm |
| 10mm | 50mm | 26mm | 17mm | 6.4mm | 1.5 | 24mm |
| 10mm | 60mm | 26mm | 17mm | 6.4mm | 1.5 | 34mm |
| 10mm | 75mm | 26mm | 17mm | 6.4mm | 1.5 | 49mm |
| 10mm | 80mm | 26mm | 17mm | 6.4mm | 1.5 | 54mm |
| 10mm | 90mm | 26mm | 17mm | 6.4mm | 1.5 | 64mm |
| 10mm | 120mm | 26mm | 17mm | 6.4mm | 1.5 | 94mm |
| 10mm | 110mm | 26mm | 17mm | 6.4mm | 1.5 | 84mm |
| 10mm | 130mm | 32mm | 17mm | 6.4mm | 1.5 | 98mm |
| 10mm | 140mm | 32mm | 17mm | 6.4mm | 1.5 | 108mm |
| 10mm | 150mm | 32mm | 17mm | 6.4mm | 1.5 | 118mm |
| 10mm | 160mm | 32mm | 17mm | 6.4mm | 1.5 | 128mm |
| 10mm | 170mm | 32mm | 17mm | 6.4mm | 1.5 | 138mm |
| 10mm | 180mm | 32mm | 17mm | 6.4mm | 1.5 | 148mm |
| 10mm | 190mm | 32mm | 17mm | 6.4mm | 1.5 | 158mm |
| 10mm | 200mm | 32mm | 17mm | 6.4mm | 1.5 | 168mm |
| 10mm | 210mm | 45mm | 17mm | 6.4mm | 1.5 | 165mm |
| 10mm | 220mm | 45mm | 17mm | 6.4mm | 1.5 | 175mm |
| 10mm | 230mm | 45mm | 17mm | 6.4mm | 1.5 | 185mm |
| 10mm | 240mm | 45mm | 17mm | 6.4mm | 1.5 | 195mm |
| 10mm | 250mm | 45mm | 17mm | 6.4mm | 1.5 | 205mm |
| 10mm | 35mm | 26mm | 17mm | 6.4mm | 1.5 | 9mm |
| 10mm | 45mm | 26mm | 17mm | 6.4mm | 1.5 | 19mm |
| 10mm | 55mm | 26mm | 17mm | 6.4mm | 1.5 | 29mm |
| 10mm | 65mm | 26mm | 17mm | 6.4mm | 1.5 | 39mm |
| 10mm | 70mm | 26mm | 17mm | 6.4mm | 1.5 | 44mm |
| 10mm | 85mm | 26mm | 17mm | 6.4mm | 1.5 | 59mm |
| 10mm | 95mm | 26mm | 17mm | 6.4mm | 1.5 | 69mm |
Please Note: Specifications given are intended as a guide only. If critical to your project please check with us first.
