Product Description
M10 Class 10.9 Self Colour Socket Button Flange Screws – ISO 7380-2
M10 socket button flange screws manufactured from Class 10.9 steel with a self colour finish. The rounded button head incorporates a flange that provides a wider bearing surface beneath the head.
Featuring an M10 x 1.5mm metric coarse thread and internal hexagon drive for installation with a 6mm Allen key. Suitable for matching M10 coarse-thread nuts or tapped holes.
Technical Specifications
| Thread size | M10 (10mm nominal diameter) |
|---|---|
| Thread pitch | 1.5mm – metric coarse |
| Material | High tensile steel |
| Material property class | 10.9 |
| Finish | Self colour / unplated |
| Head style | Button head with integral flange |
| Drive type | Internal hexagon socket |
| Allen key size | 6mm |
| Maximum flange diameter | 21.9mm |
| Maximum head height | 5.5mm |
| Dimensional standard | ISO 7380-2 |
Key Features
- Rounded button head with an integral load-spreading flange.
- Class 10.9 steel construction.
- 6mm hexagon socket drive.
- M10 x 1.5mm coarse thread.
- Self colour finish.
Size Selection
Choose the required length and thread option from the available selections. Screw length is measured from beneath the head to the tip, excluding the head.
Applications
Suitable for brackets, panels, machinery and general assemblies where a rounded head and broad bearing surface are required.
Button head screws have reduced loadability because of their head geometry. Select tightening torque and service loads for this screw type rather than using values for standard Class 10.9 hexagon bolts.
Standard
ISO 7380-2 – hexagon socket button head screws with collar.
