Product Description
No.12 Zinc Plated Steel Countersunk Pozi Self Tapping Screws – DIN 7982
No.12 countersunk Pozi self tapping screws manufactured from zinc plated steel. The 5.5mm nominal diameter and pointed AB-style end suit compatible applications using a correctly prepared pilot hole.
The countersunk head provides a flush finish when seated in a suitable countersink. The PZ3 recess accepts a matching Pozidriv screwdriver or driver bit.
Technical Specifications
| Screw size | No.12 |
|---|---|
| Nominal diameter | 5.5mm |
| Listed length | 2" (approximately 50mm) |
| Material | Steel |
| Finish | Zinc plated |
| Head style | Countersunk |
| Drive type | Pozi / Pozidriv |
| Driver size | PZ3 |
| Point style | AB |
| Standard | DIN 7982 |
Key Features
- Self tapping thread forms a mating thread in a suitable prepared hole.
- Countersunk head for flush-fitting assemblies.
- PZ3 drive for use with a matching Pozidriv bit.
- Zinc plating helps protect the steel against corrosion.
Size and Ordering
Listed length: 2", described as approximately 50mm. Countersunk screw length is measured overall, including the head. Choose the required pack quantity from the available options.
Applications and Installation
Suitable for panels, brackets, fittings and general repairs in compatible materials. Select the pilot hole to suit the material and thickness, and use a correctly fitting PZ3 driver.
Standard
DIN 7982 – cross-recessed countersunk head tapping screws.
