Product Description
M12 ZINC PLATED STEEL 10.9 GRADE HEXAGON HEAD BOLTS DIN931- 10.9 Grade Zinc Plated Steel
- Metric M12 Thread (1.75mm pitch)
- Part Threaded Bolt
| A | B | C | D | E | F | G |
| 12 | 45 | 30 | 19 | 7.5 | 1.75 | 15 |
| 12 | 50 | 30 | 19 | 7.5 | 1.75 | 20 |
| 12 | 55 | 30 | 19 | 7.5 | 1.75 | 25 |
| 12 | 60 | 30 | 19 | 7.5 | 1.75 | 30 |
| 12 | 65 | 30 | 19 | 7.5 | 1.75 | 35 |
| 12 | 70 | 30 | 19 | 7.5 | 1.75 | 40 |
| 12 | 80 | 30 | 19 | 7.5 | 1.75 | 50 |
| 12 | 90 | 30 | 19 | 7.5 | 1.75 | 60 |
| 12 | 100 | 30 | 19 | 7.5 | 1.75 | 70 |
| 12 | 110 | 30 | 19 | 7.5 | 1.75 | 80 |
| 12 | 120 | 30 | 19 | 7.5 | 1.75 | 90 |
| 12 | 130 | 30 | 19 | 7.5 | 1.75 | 100 |
| 12 | 140 | 30 | 19 | 7.5 | 1.75 | 110 |
| 12 | 150 | 30 | 19 | 7.5 | 1.75 | 120 |
Please Note: Specifications given are intended as a guide only. If critical to your project please check with us first.
