Product Description
Metric brass hex cap nuts manufactured to DIN 917, suitable for covering exposed metric threads and providing a neat finished appearance.
These low-profile hexagon cap nuts are made from CU2/CU3 grade brass with a metric coarse thread. The closed-end design helps protect exposed threads while giving a tidy decorative finish, making them suitable for machinery, electrical work, furniture, restoration, model engineering and general fastening applications.
- Thread form: Metric coarse
- Material: CU2/CU3 grade brass
- Nut type: Hex cap nut / low dome cap nut
- Standard: DIN 917
- Finish: Natural brass
- Available sizes: M3, M4, M5, M6, M8, M10, M12 and M14
- Available pack sizes: 1, 5, 10, 20, 50, 100, 250 and 500
| A | B | C | D |
| 3mm | 5.5mm | 4mm | 0.5 |
| 4mm | 7mm | 5.5mm | 0.7 |
| 5mm | 8mm | 7mm | 0.8 |
| 6mm | 10mm | 9mm | 1 |
| 8mm | 13mm | 12mm | 1.25 |
| 10mm | 16mm | 14mm | 1.5 |
| 12mm | 19mm | 16mm | 1.75 |
| 14mm | 22mm | 18mm | 2 |
Please Note: Specifications given are intended as a guide only. If critical to your project please check with us first.
