Product Description
8-36 UNF A2 Stainless Steel Pan Phillips Machine Screws
Fully threaded 8-36 UNF pan-head Phillips machine screws manufactured from corrosion-resistant A2 stainless steel. The fine 36 TPI thread is designed for use with a compatible No. 8-36 UNF nut or tapped hole.
The rounded pan head provides a broad bearing surface, while the Phillips cross recess allows straightforward installation with a compatible screwdriver or driver bit. These imperial machine screws are suitable for engineering, machinery, automotive, restoration, maintenance and general assembly applications.
Product specifications
- Thread size: No. 8-36 UNF
- Nominal thread diameter: 0.164"
- Thread pitch: 36 threads per inch
- Length: 3/4"
- Material: A2 stainless steel
- Head style: Pan head
- Drive: Phillips cross recess
- Thread coverage: Fully threaded
- Length measurement: From beneath the head
- Dimensional reference: ASME B18.6.3
Browse our complete range of UNF pan Phillips machine screws, including 10-32 UNF pan Phillips machine screws and 1/4" UNF pan Phillips machine screws. An 8-32 UNC pan Phillips version is also available for applications requiring the coarser No. 8 thread.
For further information, see our UNC and UNF thread data guide and A2 versus A4 stainless steel guide.
Dimensions are provided as a guide. If any measurement or standard compliance is critical to your application, please contact us before ordering.
| A | B | C | D | E |
| 8-36 | 3/4" | * | * | 36 |
Please Note: Specifications given are intended as a guide only. If critical to your project please check with us first.
