Product Description
10-32 UNF A2 Stainless Steel Countersunk Phillips Machine Screws
Fully threaded 10-32 UNF countersunk Phillips machine screws manufactured from corrosion-resistant A2 stainless steel. The fine 32 TPI thread is designed for use with a compatible 10-32 UNF nut or tapped hole.
The flat countersunk head is designed to sit flush with the surrounding surface when installed in a correctly formed countersunk hole. A Phillips cross recess provides convenient installation for engineering, machinery, automotive, restoration, maintenance and general assembly applications.
Product specifications
- Thread size: No. 10-32 UNF
- Nominal thread diameter: 0.190"
- Thread pitch: 32 threads per inch
- Material: A2 stainless steel
- Head style: Flat countersunk
- Drive type: Phillips cross recess
- Thread coverage: Fully threaded
- Length measurement: Overall length, including the head
- Dimensional reference: ASME B18.6.3
Available sizes
| Thread size | Overall length | Thread pitch |
|---|---|---|
| 10-32 UNF | 1/4" | 32 TPI |
| 10-32 UNF | 1/2" | 32 TPI |
| 10-32 UNF | 3/4" | 32 TPI |
| 10-32 UNF | 1" | 32 TPI |
ASME reference dimensions
- Typical head diameter: Approximately 0.362"
- Typical head length: Approximately 0.116"
- Typical countersink angle: 80–82°
- Typical drive size: PH2
These are reference dimensions for comparable ASME B18.6.3 screws. Please confirm them against the supplied stock if they are critical to your application.
Alternative head styles include our 10-32 UNF raised countersunk Phillips screws, 10-32 UNF countersunk slotted screws and 10-32 UNF countersunk socket screws.
You can also view our UNC and UNF thread data guide and A2 versus A4 stainless steel guide.
Specifications are provided as a guide. If a particular measurement or standards compliance is critical, please contact us before ordering.
