6.4mm Sealed Dome Pop Rivets ISO 15973

Product Description

6.4mm Aluminium/Steel Sealed Dome-Head Blind Rivets

These 6.4mm sealed blind rivets feature an aluminium-alloy rivet body and a steel break-pull mandrel. Their closed-end construction helps restrict the passage of moisture, air and contaminants through the centre of the installed rivet when compared with a conventional open-end blind rivet.

The dome, or protruding, head provides a broad bearing surface while blind installation allows the rivet to be fitted where access is available from only one side of the workpiece.

Product Details

• Nominal rivet diameter: 6.4mm
• Rivet body length: 12mm
• Grip range: 1.5–6.5mm
• Rivet type: Closed-end sealed blind rivet
• Head style: Dome / protruding head
• Published head diameter: 13.4mm
• Recommended hole diameter: 6.5mm
• Body material: Aluminium alloy
• Mandrel material: Steel
• Installation: Blind – access required from one side only
• Dimensional pattern: ISO 15973
• British adoption: BS EN ISO 15973:2001

Features and Benefits

• Closed-end body helps reduce the passage of moisture and contaminants
• Blind installation requires access from only one side
• Lightweight aluminium-alloy body with a steel pull mandrel
• Dome head provides a broad bearing surface
• Suitable for joining material stacks from 1.5mm to 6.5mm thick
• Larger 6.4mm diameter for suitable fabrication and engineering work
• ISO 15973-style aluminium/steel closed-end construction

Typical Applications

Suitable for sheet-metal fabrication, vehicle and trailer panels, enclosures, ducting, signs, appliances, maintenance and general engineering applications where installation is possible from only one side.

Choosing and Installing the Rivet

This rivet is intended for a total combined material thickness between 1.5mm and 6.5mm. The grip range refers to the complete thickness of all materials being joined, not the 12mm rivet body length.

Drill or prepare a clean 6.5mm installation hole. Remove burrs and hold the materials firmly together before inserting and setting the rivet. Use a riveting tool and nosepiece rated for 6.4mm blind rivets.

Because 6.4mm rivets require greater setting force than smaller diameters, confirm that the installation tool has sufficient capacity before use.

Sealing Guidance

Closed-end rivets provide improved sealing compared with conventional open-end blind rivets. However, the finished joint should not automatically be assumed to be completely waterproof, airtight or pressure-tight.

Joint design, hole condition, surface finish and installation quality all affect sealing performance. Use a suitable sealant or sealing washer where a verified watertight or airtight joint is required.

Please note that published dimensions and specifications are intended as a guide. Confirm any safety-critical, structural or sealing requirements before ordering.
